1207 – Stepper Motor: Bipolar, 200 Steps/Rev, 35x26mm, 7.4V, 280

This hybrid bipolar stepping motor has a 1.8° step angle (200 steps/revolution). Each phase draws 280 mA at 7.4 V, allowing for a holding torque of 650 g-cm (9 oz-in). The motor has four color-coded wires terminated with bare leads. Our 5mm universal mounting hub (see related products) can be used to mount objects on the stepper motor’s 5mm-diameter output shaft.  Specifications Size: 35 mm square x 26 mm, not including the shaft (NEMA 14) Weight: 130 g (4.5 oz) Shaft diameter: 5 mm Steps per revolution: 200 Current rating: 280 mA per coil Voltage rating: 7.4 V Resistance: 26 Ohm per coil Holding torque: 650 g-cm (9 oz-in) Inductance: 19.2 mH per coil Lead length: 12 in Dimensions The following diagram shows the stepper motor dimensions in mm. The dimension labeled “length” is 26 mm. The output shaft has a length of 21 mm and a diameter of 5 mm. SY35ST26-0284A stepper motor datasheet
