Yamaha F150 XB

Description Fun four-cylinder excitement. This new unit offers fresh styling and modern design, aligning the aesthetics of the Premium and High Power segments. The design cues and graphics on this engine are all pointers to the exciting technology that lives just inside. The 150hp engine benefits from enhanced connectivity for greater control and confidence, linking with Helm Master EX®, Yamaha’s latest CL5 gauge and the latest Drive-by-Wire throttles for smooth shifting, with single and multiple engine throttles available. Specification Engine Engine type 4-stroke, DOHC, In-Line Four-Cylinder, 16-valves Displacement 2,670 cm³ Bore x stroke 94.0 × 96.2 mm Max prop shaft output 110.3 kW (150 ps) Full throttle operating range 5,000 - 6,000 rpm Lubrication system Wet sump Fuel Induction System EFI Ignition / advance system TCI Gear ratio 2.0 (28/14) Dimensions Recommended boat transom height L / X (516 / 643 mm) Overall length 920 mm Overall width 548 mm Overall height L: 1742 mm, X: 1869 mm Fuel tank capacity - Engine oil capacity 4.5 L / 4.3 L (with / without oil fi lter replacement) Dry weight 222 – 227 kg Additional Features Control Remote Control Trim ― (continuously variable) Alternator 35 A (battery charging: 21 A) Propeller Optional Downloads Factsheet
